| Specifications: |
| Infusion Mode | Micro and continuous injection |
| Syringes | 5mL,10mL, 20mL, 30mL, 50/60mL syringes |
| and self-defined for customer's brand. |
Rate Unit
(including drug weight unit) | mL/h, mg/h, µg/h, |
| µg/kg/min, mg/kg/min, µg/kg/h, mg/kg/h. |
| Flow Rate Range | 5ml syringe: 0.01-60mL/h |
| 10mL syringe: 0.01 ~ 300 mL/h |
| 20mL syringe: 0.01 ~ 400 mL/h |
| 30mL syringe: 0.01 ~ 600 mL/h |
| 50mL syringe: 0.01 ~ 1200 mL/h |
| Increment | 0.01 mL/h steps (for settings from 0.01 to 99.99 mL/h); 1 mL/h steps (for settings from 100 to 999 mL/h) |
| Volume Limit | 0.1~ 9999.9 mL and empty mode available |
| Flow Rate Deviation | ≤ ± 2% |
| Purge Rate | 5ml syringe: 60mL/h |
| 10mL syringe: 300 mL/h |
| 20mL syringe: 400 mL/h |
| 30mL syringe: 600 mL/h |
| 50mL syringe: 1200 mL/h |
| KVO Rate | 0.01 ~ 5 mL/h (adjustable) |
| Bolus Mode | Bolus rate adjustable, Automatic |
| Occlusion Pressure | Pressure detection device with |
| 10 sensitivities setting, 10 ~ 140KPa. |
| Parameter Changing During Syringe | Yes, VTBI and Rate can be changed |
| History (Event Log) | 10000 events can be stored and exported |
| Drug Library | Hundreds drugs can be imported and exported. |
| Alarming and Button Sound Setting | 10 levels setting |
| Display | 3.5" TFT color LCDdisplay |
| Keypad Mode | Numerical button |
| Keypad Lock | Yes, optional |
| Power Source | AC: 100V ~ 240V, 50Hz/60Hz, ≤ 25VA |
| Battery | Rechargeable Lithium battery: DC11.1V, 3000mAh, workinghours≥7 hours at 5mL/h, remaining battery displayed. |
| Classification | Class II, CF, IPX4 |
| Dimensions and N.W. | 340mm x 200mm x 158mm; 2.1kg |
| Accessory: |
|
| Power cord | 1 pc |
| Operator Manual | 1 pc |
| Packing: |
|
| Inner box | 386x230x195mm |
| Carton | 480x400x425mm(4sets/CTN) |
| Warranty: | Two years |
